SWIFT Lite – a small house lift
A small house lift designed to meet the requirements of a limited budget without compromising on style and comfort.
SWIFT Lite has many of the SWIFT Pro features such as EcoDrive, AntiTrap, SWIFT Safety and SWIFT Remote, but comes with classic elevator buttons and only has a limited range of design options.
The lift colour is Traffic White with an image bond Artwall with Sidelights of white LED. The carpet is a sand grey EcoNyl EGE Carpet. SWIFT Lite comes in 4 different sizes.
Select design combinations
Each design theme has been carefully developed by SWIFT with inspiration from nature, interior home design and the usage of technology and light. Make sure your lift blends in or stands out as an art piece.
Lift color:
Traffic White
Lift carpet:
Una Micro Grey
Lift colours
Choose one of the following 3 colours for your residential lift.
Traffic White
RAL 9016
Jet Black
RAL 9005
Gold
RAL 1036
Carpet
SWIFT Lite comes with a Vinyl Black flooring as standard. As option you can choose Una Micro Grey from Danish design company Ege Carpet. The yarn is then recycled micro fibre.
Vinyl Black
(standard)
Ege – Una MicroGrey (optional)
SWIFT Safety
A house should be safe for all members of your family – children, grandparents and pets included. That is why we developed safety sensors and smart doors to prevent children’s fingers from getting squeezed and even equipped the house lift with features such as child lock or options to restrict users from accessing certain areas of your home. We also made sure our house lift has dual safety breaks for complete peace of mind. All lifts can be remotely accessible by our SWIFT service team ready to provide quick support if need be.
Anti-trap system
For complete peace of mind. Thanks to the Tesla-inspired battery solution you don’t need to worry about getting trapped inside the lift in case there is a mains power failure. SWIFT’s unique “anti-trap” system will ensure that the house lift continues to operate with normal speed and functionality.
Control system
The lift computing software is powered by Thor Engineering™– one of the most powerful, smart and reliable elevator control systems in the world. In general the system responds 20% quicker to user commands than other systems on the market.
A small house lift, but with maximised sizes.
Floor size: 830×600 mm
Rated load: 250 kg / 2 persons
Hole through floor: 940×1025 mm
Floor size: 830×850 mm
Rated load: 250 kg / 3 persons
Hole through floor: 940×1275 mm
Floor size: 830×1000 mm
Rated load: 250 kg / 3 persons
Hole through floor: 940×1425 mm
Floor size: 830×1100 mm
Rated load: 250 kg / 3 persons
Hole through floor: 940×1525 mm
Floor size: 1200×1000 mm
Rated load: 400 kg / 5 persons
Hole through floor: 1310×1425 mm
Floor size: 1400×1100 mm
Rated load: 400 kg / 5 persons
Hole through floor: 1510×1525 mm
Technical specifications – SWIFT Pro
GENERAL
Number of floors: 2 to 6 floors
Weight capacity: 250 kg/ 3 persons or 400 kg/ 5 persons
Speed: 0.15 m/s (0,3m/s optional)
Drive: Screw & Nut EcoDrive with Dynamic Charge
Power Supply: 220 V 1-phase, 6A (8A fuse), 900W
Control system: Thor Engineering™
Lift control: One Touch
Anti-Trap system: Included (Full operation battery backup)
Automatic lubrication: Included
Smart Home Integration: No
SWIFT Safety: Included
Technical Compliance: European Machinery Directive 2006/42/EC / European standard EN81-41
Sustainability: More than 90% recycable material
THE SHAFT
Color of shaft: Traffic White RAL 9016, Jet Black RAL 9005
(Color type: Jotun Anti-Scratch with Sahara texture finish and gloss 12%)
Total travel: 250 to 15 000 (mm)
Top height: 2 275 to 3 500 (mm)
Doors / Floor: 1
Shaft light: No
Ceiling: Ceiling and Top Lid optional
Shaft material: Steel (10 mm) and laminated clear glass (10 mm)
Doors: Double glass doors
Automatic door openers/closer: Included
Backside cover: Optional
THE PLATFORM
Platform sizes (mm): S, M, L, XL
Carpet: Vinyl Black (standard), Ege Carpet ECONYL© – Una Micro Grey (optional)
ArtWall: Image Bond White
Side lights: White 6500K
Control panel: Touch Buttons
Emergency phone: Optional – Safeline™ with cable or GSM
Emergency stop button: Included
Platform bottom cover: No
INSTALLATION AND SERVICE:
Installation: Recessed installation 50 mm in a pit or directly on floor with a door sill
Warranty: 5 years of lift, 10 years of drive (see conditions)
SWIFT Remote: Optional
EcoDrive
Easy installation
A-rated energy consumption
Customisable
Patented (pending) drive system
Anti-trap system
SWIFT remote
Environmentally friendly
Technical compliance
