SWIFT Pro – our most advanced residential lift
SWIFT Pro is our most advanced residential lift with premium design features, a dynamic touch display and several options for personalised settings.
Pushing visual boundaries of contemporary design.
When designing the SWIFT residential lift, we set out to combine technology and aesthetics in a brand new way. Light, colours, contours and audio work together to push the boundaries of what contemporary interior design can achieve.
Select design combinations
Each design theme has been carefully developed by SWIFT with inspiration from nature, interior home design and the usage of technology and light. All ArtWalls and carpets are easy to change over time. Make sure your residential lift blends in or stands out as an art piece.
ArtWall:
Electric Opal
Lift color:
Traffic white
Lift carpet:
Stitch Black
Customizable
Set floor names, add descriptions and choose icons from the SWIFT library.
Colourful
Simply adjust the shaft light colour and intensity on the display.
A residential lift with intelligence
Intuitive instructions in the display when the lift wants to tell you something.
Lift colours
Choose one of the following 5 colours for your residential lift.
Traffic White
RAL 9016
Grey White
RAL 9002
Anthracite Grey
RAL 7016
Jet Black
RAL 9005
Gold
RAL 1036
Carpets
You can choose between 5 carpeted flooring options for your SWIFT Pro. All our carpets are made by Ege Carpets, a Danish design company that is now one of Europe’s leading manufacturers of sustainable high-quality carpets. The carpets are made with ECONYL©, microfibers from nylon waste and recycled plastic bottles from the ocean.
Denim
Blue
Stitch
Green
Stitch
Black
Denim
Stripe
Linen
Grey
SWIFT Safety
A home should be safe for all members of your family – children, grandparents and pets included. That is why we developed safety sensors and smart doors to prevent children’s fingers from getting squeezed and even equipped the lift with features such as child lock or options to restrict users from accessing certain areas of your home. We also made sure our residential lift has dual safety breaks for complete peace of mind. All lifts can be remotely accessible by our SWIFT service team ready to provide quick support if need be.
Anti-trap system
For complete peace of mind. Thanks to the Tesla-inspired battery solution you don’t need to worry about getting trapped inside the lift in case there is a mains power failure. SWIFT’s unique “anti-trap” system will ensure that the residential lift continues to operate with normal speed and functionality.
Control system
The residential lift computing software is powered by Thor Engineering™- one of the most powerful, smart and reliable elevator control systems in the world. In general the system responds 20% quicker to user commands than other systems on the market.
A residential lift that is small on the outside. Big on the inside.
Floor size: 830×600 mm
Rated load: 250 kg / 2 persons
Hole through floor: 940×1025 mm
Floor size: 830×850 mm
Rated load: 250 kg / 3 persons
Hole through floor: 940×1275 mm
Floor size: 830×1000 mm
Rated load: 250 kg / 3 persons
Hole through floor: 940×1425 mm
Floor size: 830×1100 mm
Rated load: 250 kg / 3 persons
Hole through floor: 940×1525 mm
Floor size: 1200×1000 mm
Rated load: 400 kg / 5 persons
Hole through floor: 1310×1425 mm
Floor size: 1400×1100 mm
Rated load: 400 kg / 5 persons
Hole through floor: 1510×1525 mm
Technical specifications – SWIFT Pro
GENERAL
Number of floors: 2 to 6 floors
Weight capacity: 250 kg/2-3 persons or 400 kg/ 5 persons
Speed: 0.3 m/s (adjustable by user from touch display)
Drive: Screw & Nut EcoDrive with Dynamic Charge
Power Supply: 220 V 1-phase, 6A (8A fuse), 900W
Control system: Thor Engineering™
Lift control: One Touch
Anti-Trap system: Included (Full operation battery backup)
Automatic lubrication: Included
Smart Home Integration: Optional – 8 I/O card
SWIFT Safety: Included
Technical Compliance: European Machinery Directive 2006/42/EC / European standard EN81-41
Sustainability: More than 95% recycable material
THE SHAFT
Color of shaft: Traffic White (RAL 9016), Grey White (RAL 9002), Anthracite Grey (RAL 7016), Jet Black (RAL 9005)
(Color type: Jotun Anti-Scratch with Sahara texture finish and gloss 12%)
Total travel: 250 to 15 000 (mm)
Top height: 2 275 to 3 500 (mm)
Doors / Floor: 1
Shaft light: Optional – White 6500K (adjustable from display)
Ceiling: Ceiling with white LED 6500K included. RGB LED and Top Lid optional.
Shaft material: Steel (10 mm) and laminated clear glass (10 mm)
Doors: Double glass doors
Automatic door openers/closer: Included
Backside cover: Optional
THE PLATFORM
Platform sizes : XXS, XS, S, M, L, XL
Carpet: Ege Carpet ECONYL© – Denim Blue, Stitch Green, Stitch Black, Denim Stripe, Linen Grey
ArtWall: Opal with LED, Orientalic White with LED, Bird with LED, Stockholm Grid with LED, Bamboo with LED.
Side lights: White 6500K
Control panel: 10-inch dynamic touch display.
Emergency phone: Safeline™ with cable or GSM
Emergency stop button: Included
Platform bottom cover: Optional
INSTALLATION AND SERVICE:
Installation: Recessed installation 50 mm in a pit or directly on floor with a door sill
Warranty: 5 years of lift, 10 years of drive (see conditions)
SWIFT Remote: Optional
EcoDrive
Easy installation
A-rated energy consumption
User profiles
Customisable
Patented (pending) drive system
Anti-trap system
SWIFT remote
Environmentally friendly
Touch display
Technical compliance
